1. White backlight, clearly visible even in the absence of light. LCD display, resistant to temperature up to 90℃ without turning black.

2. During calibration, the slope and zero point errors are displayed, and after calibration, the electrode slope is automatically displayed.

3. The RS-485 interface output offers long range and can simultaneously output (PH,℃) or (mV,℃).

4.HI/LO PH/ORP controller (PH/ Oxidation-reduction controller) PC-201C has adjustable hysteresis time, and the controller host can be set for pH or ORP.

5. Microcomputer, single-chip processing, simultaneously displaying (PH, ℃) or (mV, ℃).

6. The main unit is made in Taiwan, and the electrodes are produced by BJC Company of the United States.

Model	PC-201C	ORP-201C
Range	0.00∽14.00PH	-100∽+1000mv
Accuracy	0.01±1digit	1±1digit
Resolution	0.01ph	1mv
Temp.Comp	Manual fixed resistance(110Ω)
	Automatic:0 to 100℃(PT-100)
Display	61/2,LCD Display with function indicator Blue back light
Oper.Temp	0 to 65℃
Current output	DC4-20mA Isolated Max.load 1kΩ
Impedance	﹥1012Ω
Control action	HI/LO Two relays
Set point	4(H1,H2/L1,L2)
Current on conect	110VAC Max.5A/240VAC MAX.3A(HI/LO)
Power	110-240VAC,50/60Hz±15%
Dimension	135*135*195mm H*W*D（Panel mounting）
Enclosure	IP65(Can be installed outdoors
